Our tractors are suitable for working on plains, hills and mountains, with stable structure Suitable for all kinds of land-forms operations.
| QINGDAO HAIJU INDUSTRIAL CO.,LTD | |||
| Tractor Model & Specification | TT254 | ||
| Drive Type | 4*4 | ||
| Dimensions of Tractor | Lenght mm | 2900 | |
| Widht mm | 1400/1500 | ||
| Height mm | 1500 | ||
| Tread | Front mm | 1200/1300 | |
| Rear mm | 1200-1300/1200-1300(Adjustable) | ||
| Wheel base mm | 1740 | ||
| Min.Ground Clearance mm | 300 | ||
| Dry Mass Kg | 1350 | ||
| Engine | Model | LD385 | |
| Type | Vertical, water-cooled, diesel engine | ||
| Number of cylinder (pcs) | 3 | ||
| Rated Power Kw（hp) | 18.3 （25） | ||
| Tyre | Front | 600-16 | |
| Rear | 9.5-24 | ||
| Clutch | Dry-type, single-acting | ||
| Steering | Hydraulic power steering | ||
| Gear box | （4+1）*2 | ||
| PTO r/min | 760 | ||
| Counterweight device | Front8*5Kg Rear2*20Kg | ||
