Our tractors are suitable for working on plains, hills and mountains, with stable structure Suitable for all kinds of land-forms operations.
QINGDAO HAIJU INDUSTRIAL CO.,LTD | |||
Tractor Model & Specification | TT254 | ||
Drive Type | 4*4 | ||
Dimensions of Tractor | Lenght mm | 2900 | |
Widht mm | 1400/1500 | ||
Height mm | 1500 | ||
Tread | Front mm | 1200/1300 | |
Rear mm | 1200-1300/1200-1300(Adjustable) | ||
Wheel base mm | 1740 | ||
Min.Ground Clearance mm | 300 | ||
Dry Mass Kg | 1350 | ||
Engine | Model | LD385 | |
Type | Vertical, water-cooled, diesel engine | ||
Number of cylinder (pcs) | 3 | ||
Rated Power Kw(hp) | 18.3 (25) | ||
Tyre | Front | 600-16 | |
Rear | 9.5-24 | ||
Clutch | Dry-type, single-acting | ||
Steering | Hydraulic power steering | ||
Gear box | (4+1)*2 | ||
PTO r/min | 760 | ||
Counterweight device | Front8*5Kg Rear2*20Kg |
