Kerb weight

5650 kg

Max. speed

20km/h

Rated bucket capacity

1.0m³

DRIVE AXLE

Rated load

2000 kg

Main transmission type

Spiral gear, first stage deceleration

Max. tractive force

32 KN

Final decelerate type

First stage, planetary gear decelerate

Max. breakout force

36 KN

TYRE

Max. gradeability

30%

Type specification

16/70-20 HD width 400mm

Max. dumping height

2730 mm

STEERING SYSTEM

Dumping distance

861 mm

Type

Articulated load-sensing hydraulic steering system

Overall dimension(L*W*H)

5387*1905*2778mm

Steering angle

32°

ENGINE

Min. turning radius

4548mm

Model

LR4B-G90A

HYDRAULIC SYSTEM

Type

Inline, direct injection, water cooling

System working pressure

28MPa

Rated power

60 kW

Lifting time

4.5s

Rated speed

2400 r/min

Total time

10s

Optional

Cummins 4BT3.9-C100

BRAKE SYSTEM

Rated speed

2200 r/min

Service brake

Mechanical internal expanding shoe-type

TRANSMISSION SYSTEM

Parking brake

Manual internal expanding shoe-type

Hydraulic torque converter

Single-stage three-element hydraulic torque converter

FILL CAPACITY

Type of gear box

Axis-fixed, double reduction

Fuel

67L

Gear shift

2 forward shift, 2 reverse shift

Hydraulic oil

90.4L
